Micronel Tube Fan D484P-024KM-4 (Option)
Compact, powerful, cost effective
In contrast to the Flat Fans, the Micronel Tube Fans offer increased pressure performance while still maintaining a high volume flow. They all feature extremely quiet and efficient operation while offering extreme reliability and life expectancy. This article is an "option with flange at inlet" based on article D481P-024KM-4.
Units for Pressure / Flow Rate
Key Features
Static Pressure 930 Pa
Freeflow 1080 l/min
Size Ø 48 mm
Voltage 24 VDC
Power Consumption 19.6 W
Electronic Motor Diver Integrated
Med. Breathing No
O2 Resistance Ambient Air (21%)
Acceleration Low
Options
Micronel Tube Fan
D484P-024KM-4 (Option)
