Micronel Radial Blower U51DL-024KK-43 (Option)
Compact, versatile, for medical breathing
This versatile and compact 24 VDC blower is the ideal choice for mobile medical respiration devices. It provides an integrated brushless driver with set-speed input and tacho output. This article is an "option with nozzles at inlet and outlet", based on article U51DL-024KK-4.
Units for Pressure / Flow Rate
Key Features
Static Pressure 5400 Pa
Freeflow 500 l/min
Size Ø 51 mm
Voltage 24 VDC
Power Consumption 41 W
Electronic Motor Diver Integrated
Med. Breathing Yes
O2 Resistance Ambient Air (21%)
Acceleration Low
Options
Micronel Radial Blower
U51DL-024KK-43 (Option)
